HSK-M Cablegland
´ Data sheet
Cable gland with an improved diaphragm closure system and NBR internal seal, with an IP68 protection rating (10 bar) according to EN 60529. Available in metric thread from M12 to M63 and in thread PG7 to PG48 for different cable diameters. Made of nickel-plated brass. Industrial and special applications.
Made of nickel-plated brass.
Protection index EN 60529: IP68 with 10 bars of pressure for immersion in water.
Improved diaphragm closure system with NBR inner seal.
Working temperature: -40°C to + 100°C.
UL Classified Certification. Certification CSA, GL, VDE, EAC, NF. CE conformance with the 2014/35 directive and the IEC 62444 standard.
Its use is recommended for the protection of wiring and conductors with high sealing requirements in industrial installations/applications and the manufacturing of OEM equipment.
-
A
SECTOR FERROVIARIO
¥ | § | ≈ | ð | † | ¤ | ∑ | p | s |
---|---|---|---|---|---|---|---|---|
PG 7 | 5 | 3 / 6.5 | 9 | 24 | 14 | 22050007 | 0.011 | 50 |
PG 9 | 6 | 4 / 8 | 11 | 27 | 17 | 22050009 | 0.018 | 50 |
PG11 | 6 | 5 / 10 | 14 | 28 | 20 | 22050011 | 0.024 | 50 |
PG13 | 6.5 | 6 / 12 | 16 | 30.5 | 22 | 22050013 | 0.029 | 50 |
PG16 | 6.5 | 10 / 14 | 18 | 29.5 | 24 | 22050016 | 0.032 | 50 |
PG21 | 7 | 13 / 18 | 22 | 31 | 30 | 22050021 | 0.052 | 25 |
PG29 | 8 | 18 / 25 | 30 | 37 | 40 | 22050029 | 0.097 | 25 |
PG36 | 8 | 22 / 32 | 39 | 43 | 50 | 22050036 | 0.160 | 10 |
PG48 | 10 | 37 / 44 | 51 | 48 | 64 | 22050048 | 0.302 | 5 |
M12 | 6.5 | 3 / 6.5 | 9 | 25.5 | 14 | 22051120 | 0.010 | 50 |
M16 | 6 | 4 / 8 | 11 | 27 | 17 | 22051160 | 0.018 | 50 |
M16 | 6 | 5 / 10 | 14 | 28 | 20 | 22051161 | 0.018 | 50 |
M20 | 6 | 6 / 12 | 16 | 29 | 22 | 22051200 | 0.029 | 50 |
M20 | 6 | 10 / 14 | 18 | 30 | 24 | 22051201 | 0.029 | 50 |
M25 | 7 | 13 / 18 | 22 | 33 | 30 | 22051250 | 0.052 | 25 |
M32 | 8 | 18 / 25 | 30 | 39 | 40 | 22051320 | 0.097 | 25 |
M40 | 8 | 22 / 32 | 39 | 45 | 50 | 22051400 | 0.168 | 10 |
M50 | 9 | 32 / 38 | 45 | 46 | 57 | 22051500 | 0.221 | 5 |
M63 | 10 | 37 / 44 | 51 | 48 | 64 | 22051630 | 0.365 | 5 |
