HSK-M-EX Cablegland
´ Data sheet
Metal cable gland with improved diaphragm closure system with NBR seal and an IP68 protection rating (10 bar) according to EN 60529. Available in metric threads from M12 to M63 and in PG7 to PG48 threads for various cable diameters. Made of nickel-plated brass. For ATEX applications with explosive atmospheres.
Made of nickel-plated brass.
ATEX Classification: II 2G 1D.
Improved diaphragm closure system with NBR inner seal.
Working temperature: -40°C to + 100°C. Protection index EN 60529: IP68 with 10 bar pressure for water immersion.
UL Classified Certification. Certification CSA, GL, VDE, EAC, NF. CE conformance with the 2014/35 directive and the IEC 62444 standard.
Its use is recommended for the protection of wiring and conductors with high sealing requirements in ATEX classified installations with risk of fire or explosion, industrial, OEM equipment manufacturing, outdoor, industrial and marine applications.
-
$
INDUSTRIA PETROQUÍMICA
¥ | § | ≈ | ð | † | ¤ | ∑ | p | s |
---|---|---|---|---|---|---|---|---|
PG13 | 6.5 | 6 / 12 | 16 | 30.5 | 22 | 22080013 | 0.030 | 50 |
M12 | 6.5 | 3 / 6.5 | 9 | 25.5 | 14 | 22081120 | 0.020 | 50 |
M16 | 6 | 4 / 8 | 11 | 27 | 17 | 22081160 | 0.020 | 50 |
M16 | 6 | 6 / 10 | 14 | 28 | 20 | 22081161 | 0.020 | 50 |
M20 | 6 | 6 / 12 | 16 | 29 | 22 | 22081200 | 0.030 | 50 |
M20 | 6 | 10 / 14 | 18 | 30 | 24 | 22081201 | 0.030 | 50 |
M25 | 7 | 14 / 18 | 22 | 33 | 30 | 22081250 | 0.050 | 25 |
M32 | 8 | 20 / 25 | 30 | 39 | 40 | 22081320 | 0.100 | 25 |
M40 | 8 | 22 / 32 | 39 | 45 | 50 | 22081400 | 0.171 | 10 |
M50 | 9 | 32 / 38 | 48 | 46 | 57 | 22081500 | 0.222 | 5 |
M63 | 10 | 37 / 44 | 51 | 48 | 64 | 22081630 | 0.295 | 5 |
