DY Derivation

´ Data sheet
DY Derivation
  • ñ
    Grey RAL 7011, Black RAL 9005
  • œ
    NW10, NW12, NW17, NW23
  • s
    10
  • n
    Polyamide 6
  • ˜
    IP54
  • ł
    -25 / 105 ºC
  • Ł
    LIBRE DE HALÓGENOS,NO PROPAGADOR DE LA LLAMA
  • ETIM
    EC002922
Y intersection in self-extinguishing polyamide 6 for a branch in Pemsaflex® conduit. Protection rating IP54, IP67 with additional inner seal. The shape of the Pemsaflex® Y intersection is used to create an angled branch in the cable run, converting one line of conduits into two.

Manufactured in polyamide 6. Self-extinguishing, halogen-free according to UNE/EN 60754-2 y UNE/EN 60754-1 and flame-retardant.

Click connection system that allows easy and fast coupling to the conduit.

Suitable for a tee joint of flexible conduits from the Pemsaflex® range.

Working temperature: -25°C to + 105°C. Degree of protection IP54 according to classification EN60529.

CE conformity to the 2014/35 directive and the IEC 61386 standard.

Suitable for the connection of Pemsaflex®, LG-PA, ST-PA, RF-PA, RB-PA and RB-PU conduits for the protection of wiring and conductors in electrical installations of machines, tools, industrial equipment, robots , vehicles and special facilities.
ñ œ ˚ ∑ p
Grey RAL 7011 NW10 NW 7 31060100 0.026
Grey RAL 7011 NW10 NW10 31060111 0.023
Grey RAL 7011 NW12 NW10 31060211 0.024
Grey RAL 7011 NW17 NW12 31060422 0.026
Grey RAL 7011 NW17 NW17 31060444 0.031
Grey RAL 7011 NW23 NW17 31060544 0.091
Black RAL 9005 NW10 NW 7 32060100 0.026
Black RAL 9005 NW10 NW10 32060111 0.023
Black RAL 9005 NW12 NW10 32060211 0.024
Black RAL 9005 NW17 NW12 32060422 0.026
Black RAL 9005 NW17 NW17 32060444 0.031
Black RAL 9005 NW23 NW17 32060544 0.091
